Full Gigabit ports, suitable for broadband access over 200M
1GHz high-end chip + 128M memory, capacity of 60 units
High gain 4 antennas, villa-level signal coverage
2.4G/5G wireless dual-band signal, fully adaptable to high-speed 5G wireless network
WeChat remote management, easy management of routers
| Standard protocol | IEEE 802.11b/g/n/ac,IEEE 802.3,IEEE 802.3u |
| Port |
1×10/100/1000M Auto MDI/MDIX RJ45 WAN port 4 ×10/100/1000M Auto MDI/MDIX RJ45 LAN port |
| Network medium | IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3u 1000Base-TX |
| Wireless rate | 2.4G：300M 5G：867M |
| Antenna |
2.4 G: 5dBi × 2, external 5G: 5dBi × 2, external |
| LED indicator | PWR, 2.4G，5G, WPS, WAN, LAN1-4 |
| Memory | 128MB DDR2 |
| Button | WPS/Default common |
| Switch | Power switch ×1 |
| Weight | 262g |
| Dimensions | 170mm ×111 mm ×21 mm （L ×W ×H） |
| Power supply | DC 12V/1A |
| Operating environment | Operating temperature: 0°C ~ 40°C Storage temperature: -20°C ~ 70°C Operating humidity: 10% ~ 90%, non-condensing Storage humidity: 5% ~ 90%, non-condensing |
| Certification | 3C |
| Packing list | Power Adapter 1, Quick Installation Guide 1, dual-band gigabit wireless router 1,1 network cable |
| Security function | DDOS attack defense Malicious URL blocking LAN attack defense Anti-Wi-Fi squatter intrusion Blacklist management |
| Basic functions | Wireless switch Troubleshooting MTU settings Connected device identification MAC address cloning Connected device management Time settings Remote management Automatic/manual upgrade Custom DNS |
| Extended function | Signal strength adjustment Child protection Guest network WISP universal relay Smart home Port mapping Peanut shell Host monitoring |
| DHCP service | DHCP server Client list Static address assignment |
| Wireless security | WPA2-PSK WPA/WPA2 Security Mechanism |
| System tools | Restore default Backup and load configuration System log Traffic statistics |
