网是科技(netcore磊科)

NW650G

650M High speed 5G wireless network card (drive free version)

Wireless dual band signal for enjoying 5G freely

No need of optical drive /no need of settings/automatic installation

With built-in high gain dual antenna, signal is strong for fast wall penetration

Mini and portable, and plugging and connecction is firm

Compatible with mainstream operating systems in the market

  • 1
  • 2
  • 3
  • 4
  • 5
1
2
3
4
5

Product parameters

Product Hardware Specifications

Product model NW650G
Standard Protocol IEEE 802.11b/g/n/ac
Port

USB 2.0

Wireless rate

11b:1/2/5.5/11Mbps

11g:6/9/12/18/24/36/48/54Mbps

11n:150Mbps

11ac:433Mbps

Wireless standard

支持IEEE802.11a标准;

支持IEEE802.11b标准;

支持IEEE802.11g标准;

支持IEEE802.11n标准;

支持IEEE802.11ac标准;

Antenna 2dBi built-in antennas
Dimensions 36.3×19×9mm(L×W×H)
Weight 5g
Operating environment

Operating temperature: 0°C ~ 40°C
Storage temperature: -20°C ~ 70°C
Operating humidity: 10% ~ 90%, non-condensingStorage humidity: 5% ~ 90%, non-condensing

Product Software Specifications

Security

WPA-PSK/WPA2-PSK

WPA/WPA2

WEP

Supported system

Windows XP/ 7 / 8 / 8.1 / 10 (32、64) /11 (64)

Other Drive free

Simulated AP
